CL1-32 Single Flange-Shaft Static Torque Sensor
Single flange-shaft static torque sensor is suitable for static torque detection or torque detection with a rotation angle less than 360 degrees. It is widely used in static torque test systems such as testing machines, torque wrenches, steering gear electric actuators, valves, and transmission static load torque hydraulics.
Features
- Suitable for measuring and controlling static torque or non-continuous rotating torque force value;
- High detection accuracy, good stability, strong anti-interference;
- Small size, light weight, easy to install;
- Inner shaft and outer shell are designed as one;
- Static torque can be measured continuously without repeated zeroing;
CL1-32 Single Flange-Shaft Static Torque Sensor Technical Parameters
| Measuring range | 0~5,10,15,20,30,50,100,200, 300, 500, 3000Nm |
| Output | 1.5mV/V±10%F.S. |
| Accuracy | ±0.1，±0.2%F.S. |
| Zero temperature effect | ±0.03%F.S. |
| Full temperature effect | ±0.03%F.S. |
| Compensated temperature range | -10~60℃ |
| Operating temperature range | -20~75℃ |
| Supply voltage | 5~10VDC |
| Input resistance | 350±20Ω |
| Output resistance | 350±10Ω |
| Response frequency | 100μS |
| Insulation resistance | ≥2000MΩ/100VDC |
| Safety overload | 150%F.S |
| Ultimate overload | 200%F.S. |
| Cable size | Φ5×3m |
| Material | Shaft material 17-4PH stainless steel, alloy steel, housing is aluminum |
| Electrical connection | Red/E+, Black/E-, Green/S+, White/S- |
Dimensions
| Range | VK | A | B | C | D |
| 5-15Nm | 1/4″ | 52.5 | 10.5 | 7.5 | φ8.5 |
| 20-50Nm | 3/8″ | 56 | 14 | 11 | φ12.8 |
| 100Nm | 1/2″ | 60 | 18 | 15 | φ17 |
| 200-500Nm | 3/4′ | 80 | 28 | 23 | φ26 |
| 1000Nm | 1″ | 85 | 33 | 28 | φ34 |
More Torque Transducers and Solutions
Single Flange-Shaft Static Torque Sensor Dimensions adopts a one-end shaft and one-end flange design. It is praised by users for its excellent stability, high measurement accuracy, high cost performance and simpler monitoring method.
The reaction torque sensor series has a parallel shaft connection for online direct drive measurement. Applications include testing of electric motors, hydraulic pumps, automotive transmissions, steering systems and aircraft actuators.
Sino-Inst produces and supplies a full range of static torque sensors. If you need to purchase or have related technical questions, please feel free to contact us!
